Compact Disc Player CD204 /00 /01 /05 /07 /10 R

Philips Belgium (Belgien)

Data

Forum

Pictures

Collections

Country
Belgium

Manufacturer / Brand
Philips Belgium (Belgien)

Year
1984/1985

Category
Sound/Video Recorder and/or Player

Radiomuseum.org ID
90733

Schematics

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534738) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534694) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534695) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534697) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534700) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534701) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534702) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534703) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534704) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534705) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534706) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534707) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534708) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534709) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534710) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534711) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534712) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534713) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534715) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534716) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534717) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534718) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534719) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534720) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534721) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534722) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534723) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534724) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534725) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2534726) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (3)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2699576) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (2)
ebay.nl #124174793759 seller schmidtaudio

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2699577) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (2)
ebay.nl #124174793759 seller schmidtaudio

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 2699578) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (2)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 924581) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (1)
The front of the Philips CD204 CD player

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 3114098) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (1)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 3114099) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (1)
Typschild zur Version CD204 /00

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 924582) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (1)
Inside of the Philips CD204/05R CD player

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 924583) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (1)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 924584) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (1)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 177791) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (2)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 177792) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (2)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 177794) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (2)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 177796) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (2)

Compact Disc Player CD204 /00 /01 /05 /07 /10 R; Philips Belgium (ID = 3114097) R-Player — Philips Belgium Compact Disc Player CD204 /00 /01 /05 /07 /10 R (1)

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Tubes
1

Valves / Tubes
9-ST-21 or FG85C1

Number of Transistors
21

Main principle
Audio-Amplification

Wave bands
- without

Details
CD-Player, -Writer, MD, MOD (audio)

Power type and voltage
Alternating Current supply (AC) / see remarks: 110 to 240 Volt

Loudspeaker
- For headphones or amp.

Material
Metal case

from Radiomuseum.org
Model: Compact Disc Player CD204 /00 /01 /05 /07 /10 R - Philips Belgium Belgien

Shape
Book-shelf unit.

Dimensions (WHD)
420 x 90 x 300 mm / 16.5 x 3.5 x 11.8 inch

Notes
14-Bit CD player with 2 TDA1540P DACs and 1 SAA7030 digital filter with 4x oversampling.

Programmable memory, headphone socket, line output leads with RCA plugs.
VFD display.

Frequency response: 20 - 20000 Hz ± 0.3 dB
SNR: < 90 dB
THD: < 0.005 % (0 dB)
Drive mechanism: CDM1

Versions (R denominates black cabinet) :
- /00 /00R
- /01 /01R
- /05R
- /07
- /10R
Power requirements:
- 110, 127, 220, 240 VAC ± 10%, adaptable by transformer modification,
  except:
- version /01 = 110, 127, 220, 240 VAC, per voltage selector
- version /07 = 117 VAC, special transformer
Semiconductors listed once per type.

The weight is stated as 7 kg in the original service manual.

Net weight (2.2 lb = 1 kg)
8.1 kg / 17 lb 13.5 oz (17.841 lb)

Mentioned in
-- Original-techn. papers. (Service manual 1984)

Literature/Schematics (1)
-- Original prospect or advert (Philips Hifi 1984/85)
