• Country
• Malaysia

• Manufacturer / Brand
• Philips Malaysia; Petaling Jaya

• Year
• 1987

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 219864

• Number of Transistors
• 4

• Semiconductors
• BC548 BC548 BC548 BC558 TEA5591 U420B

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 220/ 4 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7.6 cm = 3 inch

• Power out
• 0.6 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: D7182 /60R - Philips Malaysia; Petaling

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 260 x 170 x 90 mm / 10.2 x 6.7 x 3.5 inch

• Notes

• Eingebautes Kassettenteil für Mono- Aufnahme, eingebautes Elektretmikrofon.

  Made in Malaysia.



• Net weight (2.2 lb = 1 kg)
• 1.1 kg / 2 lb 6.8 oz (2.423 lb)

• Author
• Model page created by Wolfgang Lill. See "Data change" for further contributors.
