Diktiergerät EL3581 /00
Philips Radios - Deutschland
- Country
- Germany
- Manufacturer / Brand
- Philips Radios - Deutschland
- Year
- 1959
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 270367
-
- Brand: Deutsche Philips-Ges.
Aus Servicemanual
Q: Philips, Produkt-Katalog 1961/62
Hersteller-Prospekt
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 2
- Wave bands
- - without
- Details
- Special Tape or Cassette-Format
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 220; 245 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Diktiergerät EL3581 /00 - Philips Radios - Deutschland
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 250 x 100 x 195 mm / 9.8 x 3.9 x 7.7 inch
- Notes
-
Diktiergerät, 4,75cm/sek, 8cm-Spulen oder Bandkassette. Mikrofon mit Start/Stop-Schalter; wird auch als Lautsprecher verwendet. Statt Mikrofon kann der Tischlautsprecher VE1695 angeschlossen werden, der dann auch als Mikrofon verwendet wird.
- Net weight (2.2 lb = 1 kg)
- 4 kg / 8 lb 13 oz (8.811 lb)
- Price in first year of sale
- 349.00 DM
- Mentioned in
- -- Original-techn. papers.
| Mode d'emploi Dictaphone Philips EL3581 | 1497 KB |
- Documents regarding this model
- Author
- Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
