Double pulse generator PP1122
Philips; Eindhoven (tubes international!); Miniwatt
- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1964–1966
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 102271
Click on the schematic thumbnail to request the schematic as a free document.
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Double pulse generator PP1122 - Philips; Eindhoven tubes
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 500 x 390 x 370 mm / 19.7 x 15.4 x 14.6 inch
- Notes
- Erzeugung von einem einstellbaren Hauptimpuls mit Vorimpuls oder zweier gleicher, einstellbarer Impulse pro Periode. Frequenzbereich: 10 Hz...1 MHz. Anstiegszeit: 20 us bei 10 V Ausgangsspannung; diese ist einstellbar von 10 mV...10 V und 10...100 V.
- Net weight (2.2 lb = 1 kg)
- 38 kg / 83 lb 11.2 oz (83.7 lb)
- Price in first year of sale
- 4,290.00 DM
- Mentioned in
- -- Original prospect or advert
- Literature/Schematics (1)
- Funk-Technik (FT) (23/1965, S. 954 - 956, 998, 999 / Ausführliche Beschreibung)
- Literature/Schematics (2)
- - - Manufacturers Literature (Katalog: Philips Industrie-Elektronik 1966)
- Author
- Model page created by Hugo Sneyers. See "Data change" for further contributors.
