- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1956
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 251435
from service manual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 3
- Number of Transistors
- Semiconductors
- B250C100
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Tape Recorder
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 220; 237 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10.5 cm = 4.1 inch
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: EL3510 /20 - Philips; Eindhoven tubes
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 350 x 245 x 190 mm / 13.8 x 9.6 x 7.5 inch
- Notes
-
Tape Recorder EL3510 /20 for 6,3 mm tape.
Tracks: 2 (1 each direction).
Motor(s): 1.
Speed: 9.5 cm/sec.
Reel diameter: 13 cm.
Loudspeaker: AD3512 (5Ω).
Output for a second loudspeaker (5Ω) with automatic cut-off of internal loudspeaker.Input connector:
- Microphone: EL6100.
- Radio ou pick-up.
- Net weight (2.2 lb = 1 kg)
- 9.5 kg / 20 lb 14.8 oz (20.925 lb)
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Radiomuseum Olen Museum. See "Data change" for further contributors.
