RK14 EL3541D /22Fa

• Country
• Germany

• Manufacturer / Brand
• Philips Radios - Deutschland

• Year
• 1962

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 120937

• • Brand: Deutsche Philips-Ges.

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• EF86 ECC83 ECL82 EM84 EZ80

• Number of Transistors

• Semiconductors
• OA85

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220; 240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch

• Power out
• 2.5 W (unknown quality)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: RK14 EL3541D /22Fa - Philips Radios - Deutschland

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 350 x 170 x 300 mm / 13.8 x 6.7 x 11.8 inch

• Notes

• Philips EL 3541 D/22 Fa

  Vierpurgerät-Bandgeschwindigkeit 9,5 cm/sec - Spulen-Durchmesser bis 18cm Spulen.

• Net weight (2.2 lb = 1 kg)
• 8.2 kg / 18 lb 1 oz (18.062 lb)

• Source of data
• - - Manufacturers Literature

• Literature/Schematics (1)
• -- Schematic

• Author
• Model page created by Wilfried Winter. See "Data change" for further contributors.
