EL3546A /77

• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1963 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 81101

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 6

• Semiconductors
• OC58 or. AC107 OC57 OC44 OC75 OC74 OC74 OA85

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220; 245 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: EL3546A /77 - Philips; Eindhoven tubes

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 300 x 140 x 230 mm / 11.8 x 5.5 x 9.1 inch

• Notes

• Spaltpolmotor, Viertelspur Mono, 9,5cm/sec, Spulen-Ø: 15 cm.
  Aussteurungsinstrument.

  Similar or identical to:

  • Stella ST465 (UK)
  • Philips Continental 46, EL3546A /78 (AUS)

• Net weight (2.2 lb = 1 kg)
• 5 kg / 11 lb 0.2 oz (11.013 lb)
