• Country
• Germany

• Manufacturer / Brand
• Philips Radios - Deutschland

• Year
• 1975–1978

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 125193

• • Brand: Deutsche Philips-Ges.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220; 240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Electrophon 22GF661 /04R - Philips Radios - Deutschland

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 480 x 180 x 300 mm / 18.9 x 7.1 x 11.8 inch

• Notes

• Stereo-Plattenwechsler GC061 mit eingebautem Verstärker und zwei separaten Lautsprecherboxen für 33/45 UpM. Keramik-System GP215. Ausgangsleistung: 2× 10 W (Musik).

  Die Lautsprecher sind mit " Made in Holland " beschriftet.

• Source of data
• Handbuch VDRG 1975/1976

• Mentioned in
• Handbuch VDRG 1976/1977 (und 1977/78)

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
