- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1960 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 106238
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 110-245 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 1.8 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: F4X52A - Philips; Eindhoven tubes
- Shape
- Console, Highboy (legs > 50 %).
- Dimensions (WHD)
- 865 x 678 x 360 mm / 34.1 x 26.7 x 14.2 inch
- Notes
- Phono-Chassis = AG1025.
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Franz Born †. See "Data change" for further contributors.
