F5X12A /03 /05
Philips; Eindhoven (tubes international!); Miniwatt
- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1961–1963
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 30013
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 10
- Main principle
- Superheterodyne (common); ZF/IF 452/10700 kHz
- Tuned circuits
- 6 AM circuit(s) 11 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Details
- Record Player (not changer)
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 145; 165; 220; 245 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: F5X12A /03 /05 - Philips; Eindhoven tubes
- Shape
- Console, Highboy (legs > 50 %).
- Dimensions (WHD)
- 1075 x 650 x 405 mm / 42.3 x 25.6 x 15.9 inch
- Notes
- Rundfunk-Chassis hat Stereo-NF-Verstärker mit 2 Endstufen je 2,5 W;
Phono-Chassis = AG2056.
- Net weight (2.2 lb = 1 kg)
- 30 kg / 66 lb 1.3 oz (66.079 lb)
- Price in first year of sale
- 659.00 DM
- Source of data
- Handbuch VDRG 1962/1963
- Author
- Model page created by Iven Müller. See "Data change" for further contributors.
