• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1963/1964

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 30018

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECH81 EF89 EBC81 EL84 EM84 EZ80

• Main principle
• Superheterodyne (common); ZF/IF 452 kHz

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 90-220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: F5X35A /60 /61 - Philips; Eindhoven tubes

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 828 x 759 x 250 mm / 32.6 x 29.9 x 9.8 inch

• Notes
• Plattenspieler AG2056-00G bei Ausf. 00/01; AG2056-60G bei Ausf. 60/61

• Author
• Model page created by Iven Müller. See "Data change" for further contributors.
