F6X52A /32 /66
Philips; Eindhoven (tubes international!); Miniwatt
- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1965/1966
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 30041
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 9
- Number of Transistors
- 6
- Main principle
- Superheterodyne (common); ZF/IF 452/10700 kHz
- Wave bands
- Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 110-245 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: F6X52A /32 /66 - Philips; Eindhoven tubes
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 967 x 684 x 345 mm / 38.1 x 26.9 x 13.6 inch
- Notes
-
Ausführung /66 hat 460 kHz ZF, Pl.-Wechsler AG1025W-03.
| Solid state ombouw van een Philips buizen FM-tuner, ingebouwd in de bestaande behuizing. | 646 KB |
- Documents regarding this model
- Author
- Model page created by Iven Müller. See "Data change" for further contributors.
