- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1958/1959
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 30080
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superhet with RF-stage; ZF/IF 452 kHz
- Wave bands
- Broadcast plus more than 2 Short Wave bands.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 90-220 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: F7X85A /60 - Philips; Eindhoven tubes
- Shape
- Console with any shape - in general
- Dimensions (WHD)
- 1100 x 765 x 400 mm / 43.3 x 30.1 x 15.7 inch
- Notes
- Pl.-Wechsl. AG1005Z - 45 ( -46 bei Ausf. -60 ), 4 KW Bereiche
- Mentioned in
- - - Manufacturers Literature
- Author
- Model page created by Iven Müller. See "Data change" for further contributors.
