FA564 /00R

Philips Electronics Japan, Ltd.; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1985 ?
  • Category
  • Audio Amplifier or -mixer
  • Radiomuseum.org ID
  • 157441

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 160 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: FA564 /00R - Philips Electronics Japan, Ltd
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 420 x 97 x 290 mm / 16.5 x 3.8 x 11.4 inch
  • Notes

  • Audio-Video-Control-Center, Integrated Stereo Amplifier mit einer Ausgangsleistung von 2x80 Watt (8-16 Ohm), 2 schaltbare Lautsprechergruppen (A/B), Anschlußmöglichkeit eines Kopfhörers mit einer Impedanz von 8-1000 Ohm (Klinkenbuchse 6,3mm), Eingänge: Phono 2,5 mV an 47 kOhm, Tuner 150 mV an 25 kOhm, Tape 150 mV an 25 kOhm, CD-Player 150 mV an 25 kOhm, TV/Aux und Video/Aux 150 mV an 25 kOhm, Ausgang Tape: 150 mV an 1 kOhm, Klangregelung: +10 dB bis -10 dB bei 50, 200, 800, 3200 und 12800 Hz, Loudness: +6 dB bei 100 Hz, +3 dB bei 10 kHz, Stereobalance: 0-50 dB.

    Made in Japan for Philips by Marantz.

  • Net weight (2.2 lb = 1 kg)
  • 5.8 kg / 12 lb 12.4 oz (12.775 lb)
  • Author
  • Model page created by Museum Roggenhofer. See "Data change" for further contributors.
