- Country
- Spain
- Manufacturer / Brand
- Philips Ibérica, COPRESA, Compañía de Productos Electrónicos, Miniwatt tubes, SELEZ; Madrid, Barcelona
- Year
- 1958/1959
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 97499
Prospekt
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 14
- Main principle
- Superheterodyne (common); ZF/IF 470/10700 kHz; 6 AF stage(s)
- Tuned circuits
- 6 AM circuit(s) 10 FM circuit(s)
- Wave bands
- Broadcast, 2 Short Wave plus FM or UHF.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 150 Volt
- Loudspeaker
- 3 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: F8E84A - Philips Ibérica, COPRESA,
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 1200 x 830 x 436 mm / 47.2 x 32.7 x 17.2 inch
- Notes
-
AM: 185 - 580 m.
OC1: 59 - 187 m.
OC2: 16,7 - 58,5 m.
FM: 87,5 - 100 MHz utilizando módulo FM tipo ZB A3 696 75
- Price in first year of sale
- 29,926.25 Pesetas
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
