- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1953/1954
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 30111
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superhet with RF-stage; ZF/IF 452 kHz
- Wave bands
- Broadcast plus more than 2 Short Wave bands.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 90; 110; 125; 180; 200; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21 cm = 8.3 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: FX637A - Philips; Eindhoven tubes
- Shape
- Console with any shape - in general
- Dimensions (WHD)
- 920 x 780 x 390 mm / 36.2 x 30.7 x 15.4 inch
- Notes
- Pl.Wechsler: AG1000, 3 KW Bereiche
- Net weight (2.2 lb = 1 kg)
- 58 kg / 127 lb 12.1 oz (127.753 lb)
- Price in first year of sale
- 998.00 Hfl
- Source of data
- -- Original prospect or advert
- Author
- Model page created by Iven Müller. See "Data change" for further contributors.
