- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1951/1952
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 76508
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 10
- Main principle
- Superheterodyne (common); ZF/IF 452 kHz
- Wave bands
- Ready for FM, has Broadcast, Long Wave, several Short Wave.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 32 cm = 12.6 inch
- Power out
- 10 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: FX714A/20 - Philips; Eindhoven tubes
- Shape
- Console with any shape - in general
- Dimensions (WHD)
- 940 x 790 x 432 mm / 37 x 31.1 x 17 inch
- Notes
-
3 SW bands. With Philips 2508 record changer. Optional FM unit 7768-12 using EF41 and EF42, 87.5 - 100 MHz.
- Price in first year of sale
- 1,585.00 Hfl
- Source of data
- -- Original prospect or advert
- Mentioned in
- Technisch- Commercieel - Radio Vademecum Staleman
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Hugo Sneyers. See "Data change" for further contributors.
