Gemma 303 B3D03A dunkel

Philips Radios - Deutschland

Data
Forum
Pictures
Collections

  • Year
  • 1960/1961
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 23445
    • Brand: Deutsche Philips-Ges.

 Technical Specifications

  • Number of Tubes
  • 7
  • Main principle
  • Superheterodyne (common); ZF/IF 460/10700 kHz
  • Tuned circuits
  • 6 AM circuit(s)     10 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 117/220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Gemma 303 B3D03A [dunkel] - Philips Radios - Deutschland
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 450 x 280 x 190 mm / 17.7 x 11 x 7.5 inch
  • Notes
  • Nussbaum, dunkel
  • Net weight (2.2 lb = 1 kg)
  • 6.5 kg / 14 lb 5.1 oz (14.317 lb)
  • Price in first year of sale
  • 238.00 DM
  • External source of data
  • Erb

 Collections | Museums | Literature

Collections

The model Gemma 303 is part of the collections of the following members.

 Forum

Forum contributions about this model: Philips Radios -: Gemma 303 B3D03A

Threads: 1 | Posts: 5

Dear Radio Friends,

 While going over this set and replacing several of the filter caps, I ran into a problem.  The set blew the fuse after about 5 minutes of operations with a small bit of smoke coming from the power transformer.  I suspect a resistor or two way out of tolerance.  It was working wonderfully on all three frequency selections (UKW, LW and MW) up to this point.  Does anyone have some suggestions as to the likely suspects?

Thank you,

Bob

Bob Isaac, 27.Nov.10
