Giradischi Super 1000

Philips Italy; Milano (MI)

Data
Forum
Pictures
Collections

  • Year
  • 1970 ??
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 316271

 Technical Specifications

  • Number of Transistors
  • 5
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Rec.Player+Audio.Amp+LS
  • Power type and voltage
  • Line / Batteries (any type) / 220 / 3R12 or 3LR12: 2 x 4,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 15 cm = 5.9 inch
  • Material
  • Leather / canvas / plastic - over other material
  • from Radiomuseum.org
  • Model: Giradischi Super 1000 - Philips Italy; Milano MI
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 380 x 125 x 250 mm / 15 x 4.9 x 9.8 inch
  • Notes

  • Giradischi Philips a 3 velocità, 33 45 78 giri, con testina Philips GP 224/01.

    Commutatore manuale Rete/Batterie.

  • Net weight (2.2 lb = 1 kg)
  • 3.7 kg / 8 lb 2.4 oz (8.15 lb)
  • Author
  • Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.
