L.F. Versterker-Voltmeter - AF Amplifier-Voltmeter GM6017 /02 EF86
Philips; Eindhoven (tubes international!); Miniwatt
- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1955–1965 ?
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 81608
- Number of Tubes
- 7
- Number of Transistors
- Semiconductors
- OA70
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 110-245 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: L.F. Versterker-Voltmeter - AF Amplifier-Voltmeter GM6017 /02 [EF86] - Philips; Eindhoven tubes
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 330 x 280 x 150 mm / 13 x 11 x 5.9 inch
- Notes
-
AC-milivoltmeter/amplifier 0.01 - 300 V / 2 Hz - 200 kHz.
See also Philips GM6017 /01 with EF40 as first amplifier stage.
- Net weight (2.2 lb = 1 kg)
- 9 kg / 19 lb 13.2 oz (19.824 lb)
- Author
- Model page created by Hugo Sneyers. See "Data change" for further contributors.
