• Country
• Spain

• Manufacturer / Brand
• Philips Ibérica, COPRESA, Compañía de Productos Electrónicos, Miniwatt tubes, SELEZ; Madrid, Barcelona

• Year
• 1957

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 130252

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• ECH81 EBF80 EBC90 EL84 EZ80

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast plus 2 Short Wave bands.

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 150 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Radiofonógrafo H5E74-A Ch= B4E72-A - Philips Ibérica, COPRESA,

• Shape
• Tablemodel with Push Buttons.

• Notes

• Philips Ibérica; Radiofonógrafo H5E74-A.

  Equipo base compuesto por:

  • Receptor:     B4E 72-A
  • Tocadiscos: AG-2004-05
  • Cabezal:      AG-3010 (Cristal)
  • Altavoces:    2 unidades tipo ZB-9768 M/1 (5 Ω)
  •

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Carles Rodriguez Vila. See "Data change" for further contributors.
