H5X68A

• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1956/1957

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 30144

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• EF89 ECH81 EBF80 EBC81 EM80 EL84 UL41 EZ80

• Main principle
• Superhet with RF-stage; ZF/IF 452 kHz

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 90; 110; 127; 145; 190; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: H5X68A - Philips; Eindhoven tubes

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 650 x 448 x 404 mm / 25.6 x 17.6 x 15.9 inch

• Notes

• Wave bands:
  MW: 185 - 580 m
  SW1a: 11.40 - 16.94 m (OC2a)
  SW1b: 16.75 - 25.64 m (OC2b)
  SW1c: 25 - 60 m (OC2c)
  SW2: 59 - 187m (OC3)

  Speaker: AD3800AM (Z = 800 ohms). Record changer: AG1003-75.

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Iven Müller. See "Data change" for further contributors.
