• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1961–1966

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 93941

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 12

• Valves / Tubes
• 5718 E180F E180F E180F E180F E180F E180F PL81 PL81 EF86 E88CC 85A2 EZ81

• Number of Transistors

• Semiconductors
• OA73 OA73 OA83

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: HF-Millivoltmeter GM6014 - Philips; Eindhoven tubes

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 350 x 270 x 210 mm / 13.8 x 10.6 x 8.3 inch

• Notes

• Messbereich: 0,1 mV bis 300 mV, mit Vorabschwächer 10 mV bis 30 V. Frequenzbereich: 1 kHz bis 30 MHz. Der Messkopf ist mit dem Gerät fest verbunden.

  GR3 is a OA83 as mentioned in the 1959 'Service Documentatie' (page 4, location E3).

• Net weight (2.2 lb = 1 kg)
• 11.5 kg / 25 lb 5.3 oz (25.33 lb)

• Price in first year of sale
• 1,390.00 DM

• Mentioned in
• Radioschau, August 1961

• Literature/Schematics (1)
• -- Original-techn. papers.

• Literature/Schematics (2)
• - - Manufacturers Literature (Katalog: Philips Industrie-Elektronik 1966; Service Documentatie 1959)

• Author
• Model page created by Alexander Küffer. See "Data change" for further contributors.
