HF-Signal Generator/Oscillator GM-2883/04
Philips; Eindhoven (tubes international!); Miniwatt
- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1954 ?
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 166720
Philips GM2883-04 Front
Philips GM2883-04 Open
Philips GM2883-04 Side
Philips GM2883-04 Coils detail
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: HF-Signal Generator/Oscillator GM-2883/04 - Philips; Eindhoven tubes
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 335 x 220 x 165 mm / 13.2 x 8.7 x 6.5 inch
- Notes
- Service-oscillator, frequency range: 100 kHz - 30 MHz in 6 ranges. Diodes: 4x OA81. Signal lamps: 2x 8008N (6,3V/0,15A). See also Philips GM2883/02 and ../03.
- Net weight (2.2 lb = 1 kg)
- 8 kg / 17 lb 9.9 oz (17.621 lb)
- Literature/Schematics (1)
- -- Schematic
- Author
- Model page created by Antonio Martins-Pais. See "Data change" for further contributors.
