HF-Voltmeter GM6006
Philips; Eindhoven (tubes international!); Miniwatt
- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1950
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 99230
FT
Radio Constructeur et Dépanneur 1950
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 9
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 110-245 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: HF-Voltmeter GM6006 - Philips; Eindhoven tubes
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 330 x 275 x 180 mm / 13 x 10.8 x 7.1 inch
- Notes
- Meßbereich 1 kHz bis 30 MHz, 50 µV noch meßbar, als Breitbandverstärker verwendbar.
- Source of data
- -- Collector info (Sammler)
- Author
- Model page created by a member from A. See "Data change" for further contributors.
