Jeep N3W24T
Philips Radios - Deutschland
- Country
- Germany
- Manufacturer / Brand
- Philips Radios - Deutschland
- Year
- 1963/1964
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 25022
-
- Brand: Deutsche Philips-Ges.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 6
- Main principle
- Superheterodyne (common); ZF/IF 460 kHz
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 2 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Jeep N3W24T - Philips Radios - Deutschland
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 181 x 54 x 142 mm / 7.1 x 2.1 x 5.6 inch
- Net weight (2.2 lb = 1 kg)
- 1.750 kg / 3 lb 13.7 oz (3.855 lb)
- Price in first year of sale
- 175.00 DM
- External source of data
- Erb
- Source of data
- Handbuch VDRG 1963/1964
- Literature/Schematics (1)
- -- Original-techn. papers.
