• Country
• Great Britain (UK)

• Manufacturer / Brand
• Philips Electrical, Lamps, Industrial - Miniwatt; London

• Year
• 1962

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 222949

• Number of Transistors
• 6

• Semiconductors
• AF117 AF117 AF117 OC81 OC81 OC81

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 5 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Dry Batteries / 4 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: L2X23T/01R - Philips Electrical, Lamps,

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 180 x 110 x 50 mm / 7.1 x 4.3 x 2 inch

• Notes
• Philips L2X23T/01R;
  Made in Great Britain.

• Net weight (2.2 lb = 1 kg)
• 0.480 kg / 1 lb 0.9 oz (1.057 lb)

• Author
• Model page created by José Manuel Silvestre. See "Data change" for further contributors.
