• Country
• Germany

• Manufacturer / Brand
• Philips Radios - Deutschland

• Year
• 1957 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 327664

• • Brand: Deutsche Philips-Ges.

• Number of Tubes
• 5

• Valves / Tubes
• DF96 DF96 DK96 DF96 DF97

• Number of Transistors
• 4

• Semiconductors
• OC71 OC71 OC72 OC72

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Power type and voltage
• Storage and/or dry batteries / 6 & 90 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Bakelite case

• from Radiomuseum.org
• Model: L4X72BT /22 - Philips Radios - Deutschland

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 340 x 270 x 130 mm / 13.4 x 10.6 x 5.1 inch

• Notes

• Philips L4X72BT /22, made in Wetzlar.

• Author
• Model page created by Gidi Verheijen. See "Data change" for further contributors.
