L5W34T /01
Philips Belgium (Belgien)
- Country
- Belgium
- Manufacturer / Brand
- Philips Belgium (Belgien)
- Year
- 1963/1964
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 79275
Antenne und Tragegriff fehlen.
Identical in construction to Philips L5W34T
Identical in construction to Philips L5W34T
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 9
- Main principle
- Superheterodyne (common); ZF/IF 452/10700 kHz; 3 AF stage(s)
- Tuned circuits
- 7 AM circuit(s) 10 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Dry Batteries / 4 x 1,5 (UM1) Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: L5W34T /01 - Philips Belgium Belgien
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 315 x 220 x 95 mm / 12.4 x 8.7 x 3.7 inch
- Notes
-
Philips L5W34T /01: FM 87,5-108 MHz (Philips L5W34T /00: FM 87,5-104 MHz).
- Price in first year of sale
- 298.00 hfl
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Bernhard Nagel. See "Data change" for further contributors.
- Other Models
-
Here you find 592 models, 568 with images and 342 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Philips Belgium (Belgien)
Collections
The model is part of the collections of the following members.
Museums
The model can be seen in the following museums.
Forum contributions about this model: Philips Belgium: L5W34T /01
Threads: 1 | Posts: 3
Goodmorning,
Subject : repairing Philips L5W34T
The volume control potentiometer (R31+R32) is "scratchy". I would like to get access to it, in the easiest way, advoiding dismantling un-nessesary parts.
Could some-one give me the right procedure ?
Thank for help, Bruno Reinach.
P.S. Sory for my english (my mother language is french).
Bruno REINACH, 21.Feb.24
