• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1966 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 120828

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Dry Batteries / 2 × 9 Volt

• Loudspeaker
• - For headphones or amp.

• from Radiomuseum.org
• Model: LF -Generator PM5101 - Philips; Eindhoven tubes

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 250 x 130 x 140 mm / 9.8 x 5.1 x 5.5 inch

• Notes
• Frequenzbereich: 10 Hz...100 kHz. Sinus: 0...2 V; Rechteck: 0...-4 Vss.

• Net weight (2.2 lb = 1 kg)
• 1.5 kg / 3 lb 4.9 oz (3.304 lb)

• Price in first year of sale
• 510.00 DM

• Mentioned in
• Philips Katalog, Industrie-Elektronik, 1966

• Author
• Model page created by a member from D. See "Data change" for further contributors.
