• Country
• Italy

• Manufacturer / Brand
• Philips Italy; Milano (MI)

• Year
• 1955–1957

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 115857

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• DF96 DK92 DF96 DAF96 DM71 DL94

• Main principle
• Superhet with RF-stage; ZF/IF 460 kHz

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Power type and voltage
• Line / Batteries (any type) / 110-220 / 2 x 1,5 & 67,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch

• Power out
• 0.14 W (unknown quality)

• Material
• Bakelite case

• from Radiomuseum.org
• Model: LI437AB - Philips Italy; Milano MI

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 360 x 250 x 125 mm / 14.2 x 9.8 x 4.9 inch

• Notes
• Mobile in bachelite in diverse varianti di colore.

• Net weight (2.2 lb = 1 kg)
• 3.5 kg / 7 lb 11.3 oz (7.709 lb)

• Price in first year of sale
• 45,000.00 ITL

• Source of data
• Guida Pratica Antique Radio (1) 1999

• Mentioned in
• Catalogo ANIE (1955-56 e 1956-57)

• Author
• Model page created by Alessandro De Poi. See "Data change" for further contributors.
