Lugano TL 12RL273
Philips Radios - Deutschland
- Country
- Germany
- Manufacturer / Brand
- Philips Radios - Deutschland
- Year
- 1967 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 346156
-
- Brand: Deutsche Philips-Ges.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 460 kHz
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Dry Batteries / AA: 4 x 1.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Lugano TL 12RL273 - Philips Radios - Deutschland
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 170 x 140 x 50 mm / 6.7 x 5.5 x 2 inch
- Notes
-
See also Nicolette de Luxe 12RL273 where the schematics are reported. Both models were manufactured in Wetzlar, Germany.
Other Philips radios bear the name of cities such as Aachen, Berlin (several models), Ascona and Luzern.
- Author
- Model page created by Aldo Andreani. See "Data change" for further contributors.
