Michelangelo D24T110 D 24 T 110 Ch=D6N
Philips Radios - Deutschland
- Country
- Germany
- Manufacturer / Brand
- Philips Radios - Deutschland
- Year
- 1970/1971
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 103318
-
- Brand: Deutsche Philips-Ges.
Q: Philips, Produkt-Katalog '72
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 10
- Number of Transistors
- 13
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Details
- Remote Control (with wire or wireless)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Wooden case
- from Radiomuseum.org
- Model: Michelangelo D24T110 D 24 T 110 Ch=D6N - Philips Radios - Deutschland
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 670 x 500 x 410 mm / 26.4 x 19.7 x 16.1 inch
- Notes
-
28 Dioden, 1 IC. VHF/UHF. 24 Zoll SW-Gerät.
Anschluss für Kabelfernbedienung 68 Luxus 12ET0850.
- Net weight (2.2 lb = 1 kg)
- 27 kg / 59 lb 7.5 oz (59.471 lb)
- Source of data
- Handbuch VDRG 1970/1971
- Author
- Model page created by Franz Born †. See "Data change" for further contributors.
