Micro Hi-Fi System MC230E /22
Philips 飞利浦; China
- Country
- People's Republic of China
- Manufacturer / Brand
- Philips 飞利浦; China
- Year
- 2002 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 350053
Manufacturer documentation
Manufacturer documentation
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- PLL, Phase-locked loop; Export model
- Wave bands
- Broadcast (BC) and FM or UHF.
- Details
- CD-Player, -Writer, MD, MOD (audio); Remote Control (with wire or wireless)
- Power type and voltage
- Alternating Current supply (AC) / 220-240 Volt
- Loudspeaker
- 2 Loudspeakers
- Power out
- 20 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Micro Hi-Fi System MC230E /22 - Philips 飞利浦; China
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 250 x 245 x 98 mm / 9.8 x 9.6 x 3.9 inch
- Notes
-
Speaker dimension: 166×245×90 mm.
Model designed and developed by Philips, Europe.
Loudspeakers:
2 way Bass Reflex Speaker System
with 3" woofer and piezo tweeter
- Net weight (2.2 lb = 1 kg)
- 4.2 kg / 9 lb 4 oz (9.251 lb)
