Mullard 273MVR
Philips USA
- Country
- United States of America (USA)
- Manufacturer / Brand
- Philips USA
- Year
- 1941 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 356052
Gerät stammt aus Südafrika
Gerät stammt aus Südafrika.
Gerät stammt aus Südafrika
- Number of Tubes
- 4
- Number of Transistors
- Semiconductors
- Vibrator
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast plus more than 2 Short Wave bands.
- Power type and voltage
- Storage and/or dry batteries / 6 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Mullard 273MVR - Philips USA
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 440 x 300 x 200 mm / 17.3 x 11.8 x 7.9 inch
- Notes
-
This device is a typical "farm radio" and is powered by a 6V battery. The high-voltage rectification is achieved by a second set of contacts in the vibrator (synchronous rectification). The brand is "Mullard", but it most likely was manufactured by Philips USA for export to South Africa.
See the almost identical Philips 737VN device from 1941(?). The circuit diagram of Philips 660VN and 663VN (also farm radios) may be useful for this set as the tubes used are the same.
- Net weight (2.2 lb = 1 kg)
- 5.450 kg / 12 lb 0.1 oz (12.004 lb)
- Author
- Model page created by Siegfried Raedel. See "Data change" for further contributors.
