Digital Multimeter PM2518X

• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1984–1994

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 97460

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Dry Batteries / 4 × 1.5 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Digital Multimeter PM2518X - Philips; Eindhoven tubes

• Shape
• Miscellaneous shapes - described under notes.

• Dimensions (WHD)
• 116 x 172 x 66 mm / 4.6 x 6.8 x 2.6 inch

• Notes

• halbautomatisches Digitalmultimeter mit LCD-Anzeige 4stellig;
  AC True RMS, ACV, ACV (dB-Anzeige);
  DCV, Ohm, Ohm (mV-Azeige), Celsius (mit Probe) ACA, DCA;
  Crest-Faktor-Messfehleranzeige, Drucktasten zur manuellen Bereichseinstellung oder Nullpunktverschiebung.
  Zubehör: Kunststoffkoffer, HF-Messonde, Temp.-Messonde.
  Ähnliche Modelle sind PM2518, PM2618, PM2718 usw.

  Ausführung PM2518X/11 mit beleuchtetem Display

• Net weight (2.2 lb = 1 kg)
• 0.7 kg / 1 lb 8.7 oz (1.542 lb)

• Mentioned in
• -- Original prospect or advert (Philips Test & Messtechnik Katalog 85 / 86)

• Literature/Schematics (1)
• Funkschau (17/1984, S. 71, 72 /Ausführliche Beschreibung)
