Musi-Clock FM 22RS294

Philips Belgium (Belgien)

Data

Forum

Pictures

Collections

Country
Belgium

Manufacturer / Brand
Philips Belgium (Belgien)

Year
1970–1972

Category
Broadcast Receiver - or past WW2 Tuner

Radiomuseum.org ID
27925

Schematics

Musi-Clock FM 22RS294; Philips Belgium (ID = 233403) Radio — Philips Belgium Musi-Clock FM 22RS294 (3)

Musi-Clock FM 22RS294; Philips Belgium (ID = 233405) Radio — Philips Belgium Musi-Clock FM 22RS294 (3)

Musi-Clock FM 22RS294; Philips Belgium (ID = 233406) Radio — Philips Belgium Musi-Clock FM 22RS294 (3)

Musi-Clock FM 22RS294; Philips Belgium (ID = 233407) Radio — Philips Belgium Musi-Clock FM 22RS294 (3)

Musi-Clock FM 22RS294; Philips Belgium (ID = 233399) Radio — Philips Belgium Musi-Clock FM 22RS294 (3)

Musi-Clock FM 22RS294; Philips Belgium (ID = 1226042) Radio — Philips Belgium Musi-Clock FM 22RS294 (1)

Musi-Clock FM 22RS294; Philips Belgium (ID = 128309) Radio — Philips Belgium Musi-Clock FM 22RS294 (2)
Q= servicemanual

Musi-Clock FM 22RS294; Philips Belgium (ID = 221127) Radio — Philips Belgium Musi-Clock FM 22RS294 (2)

Musi-Clock FM 22RS294; Philips Belgium (ID = 381232) Radio — Philips Belgium Musi-Clock FM 22RS294 (2)

Musi-Clock FM 22RS294; Philips Belgium (ID = 1226028) Radio — Philips Belgium Musi-Clock FM 22RS294 (1)

Musi-Clock FM 22RS294; Philips Belgium (ID = 1226030) Radio — Philips Belgium Musi-Clock FM 22RS294 (1)

Musi-Clock FM 22RS294; Philips Belgium (ID = 1226031) Radio — Philips Belgium Musi-Clock FM 22RS294 (1)

Musi-Clock FM 22RS294; Philips Belgium (ID = 1226033) Radio — Philips Belgium Musi-Clock FM 22RS294 (1)

Musi-Clock FM 22RS294; Philips Belgium (ID = 1226038) Radio — Philips Belgium Musi-Clock FM 22RS294 (1)

Musi-Clock FM 22RS294; Philips Belgium (ID = 1226039) Radio — Philips Belgium Musi-Clock FM 22RS294 (1)

Musi-Clock FM 22RS294; Philips Belgium (ID = 1226045) Radio — Philips Belgium Musi-Clock FM 22RS294 (1)

Musi-Clock FM 22RS294; Philips Belgium (ID = 1511783) Radio — Philips Belgium Musi-Clock FM 22RS294 (2)
Prospeto de 1971

Musi-Clock FM 22RS294; Philips Belgium (ID = 1615256) Radio — Philips Belgium Musi-Clock FM 22RS294 (1)

Musi-Clock FM 22RS294; Philips Belgium (ID = 1615257) Radio — Philips Belgium Musi-Clock FM 22RS294 (1)

Musi-Clock FM 22RS294; Philips Belgium (ID = 1615258) Radio — Philips Belgium Musi-Clock FM 22RS294 (1)

Musi-Clock FM 22RS294; Philips Belgium (ID = 1615259) Radio — Philips Belgium Musi-Clock FM 22RS294 (1)

Musi-Clock FM 22RS294; Philips Belgium (ID = 1615260) Radio — Philips Belgium Musi-Clock FM 22RS294 (1)

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Transistors
8

Semiconductors
BF195 BF195 BF194 BF195 BC148 BC158 AC187 AC188 OF160 BZY88 AA119 BA102

Main principle
Superheterodyne (common); ZF/IF 460/10700 kHz

Tuned circuits
4 AM circuit(s) 8 FM circuit(s)

Wave bands
Broadcast (BC) and FM or UHF.

Power type and voltage
Alternating Current supply (AC) / 110; 127; 220; 242 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

Power out
1 W (unknown quality)

Material
Plastics (no bakelite or catalin)

from Radiomuseum.org
Model: Musi-Clock FM 22RS294 - Philips Belgium Belgien

Shape
Tablemodel with Clock ((Alarm-) Clock Radio).

Dimensions (WHD)
320 x 80 x 140 mm / 12.6 x 3.1 x 5.5 inch

Notes
Eingebaute Weckuhr.
Gehäusefarben: altweiss oder anthrazit.

Net weight (2.2 lb = 1 kg)
2 kg / 4 lb 6.5 oz (4.405 lb)

Price in first year of sale
1,495.00 ATS

External source of data
Erb

Source of data
Handbuch VDRG 1970/1971

Literature/Schematics (1)
-- Original-techn. papers.

Other Models
Here you find 596 models, 572 with images and 343 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Philips Belgium (Belgien)

Collections | Museums | Literature

Collections

The model Musi-Clock FM is part of the collections of the following members.

Forum
