• Country
• Spain

• Manufacturer / Brand
• Philips Ibérica, COPRESA, Compañía de Productos Electrónicos, Miniwatt tubes, SELEZ; Madrid, Barcelona

• Year
• 1953–1957

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 172010

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• EF41 ECH42 EAF42 EBC41 EL41

• Number of Transistors

• Semiconductors
• Vibrador

• Main principle
• Superhet with RF-stage

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case

• from Radiomuseum.org
• Model: NE-536-V - Philips Ibérica, COPRESA,

• Shape
• Chassis only or for «building in»

• Notes

• Philips Ibérica, S.A., Miniwatt, Copresa, Autoradio NE536-V

  Onca Corta de 25m con posibilidad de adaptarle unidad de Onda Corta tipo AF7503 para 20, 30 y 50m.

• Price in first year of sale
• 4,426.40 ESP

• Mentioned in
• Catálogos Philips "Tío Carlos 1953" a "Novosonic 1957"

• Literature/Schematics (1)
• Anuncio La Vanguardia Española 31 Octubre 1953

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
