• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1935 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 173932

• Number of Tubes
• 6

• Valves / Tubes
• AK1 AF2 AB1 E446 E443H 506

• Main principle
• Superheterodyne (common); ZF/IF 115 kHz; 2 AF stage(s); Export model

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Alternating Current supply (AC) / 103 - 253 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21.5 cm = 8.5 inch

• Power out
• 3.1 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Octode Super 525A für Norwegen [output E443H] - Philips; Eindhoven tubes

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Dimensions (WHD)
• 355 x 410 x 240 mm / 14 x 16.1 x 9.4 inch

• Notes
• Dieses Modell wurde bei Philips Eindhoven mit eigener Skala für den norwegischen Markt gebaut.

• Net weight (2.2 lb = 1 kg)
• 10 kg / 22 lb 0.4 oz (22.026 lb)

• Author
• Model page created by a member from D. See "Data change" for further contributors.
