• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 2012–2014 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 322390

Click on the schematic thumbnail to request the schematic as a free document.

• Main principle
• PLL, Phase-locked loop

• Wave bands
• DAB and FM, perhaps with Streaming [DABFM]

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 100-240 Volt

• Loudspeaker
• 2 Loudspeakers / Ø 7.6 cm = 3 inch

• Power out
• 10 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Original Radio ORD7300 /10 - Philips; Eindhoven tubes

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 330 x 163 x 150 mm / 13 x 6.4 x 5.9 inch

• Notes

• Stereo Radio im Design der Philetta aus den 50er Jahren.

  UKW 87.5 - 108MHz  mit RDS     30 Programmspeicherplätze   UKW

  DAB+  174.928 - 239.200 MHz     30 Programmspeicherplätze   DAB

  LCD Display mit Uhr Anzeige, RDS u. DAB Daten.

  Synchronisierung der Uhr via DAB

  NF Eingang per Klinkenbuchse

  Dock Anschluß für Apple Geräte  iPod touch, iPod classic, iPod nano, iPhone bis 4S

  Fernbedienung

  Made in China.



• Net weight (2.2 lb = 1 kg)
• 3.5 kg / 7 lb 11.3 oz (7.709 lb)

• Price in first year of sale
• 229.99 Euro

• Mentioned in
• - - Manufacturers Literature

• Author
• Model page created by Heinrich Stummer. See "Data change" for further contributors.
