P263
Philips Canada
- Country
- Canada
- Manufacturer / Brand
- Philips Canada
- Year
- 1955 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 301731
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast plus 2 Short Wave bands.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- 2 Loudspeakers
- Power out
- 3 W (5 W max.)
- from Radiomuseum.org
- Model: P263 - Philips Canada
- Notes
-
The Philips model P263 is a 6-tube radio with built in record changer. Covers standard broadcast and 1.7-5.5 MHz and 5.5-18.1 MHz shortwave.
- Literature/Schematics (1)
- Radio College of Canada (RCC) (1956 supplement 37)
- Author
- Model page created by Tom Seeger. See "Data change" for further contributors.
