• Country
• Germany

• Manufacturer / Brand
• Philips Radios - Deutschland

• Year
• 1961/1962

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 24088

• • Brand: Deutsche Philips-Ges.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 3

• Valves / Tubes
• ECH81 ECH81 EL95

• Number of Transistors

• Semiconductors
• AP6016 OA85

• Main principle
• Superheterodyne (common); ZF/IF 460 kHz

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 2 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Paladin 394 N3X94V /22 - Philips Radios - Deutschland

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 175 x 54 x 100 mm / 6.9 x 2.1 x 3.9 inch

• Notes

• Philips Autoradio Paladin 394 mit zweiteiligem Gehäuse. Es gibt mehere Versionen der Skala.
  Dimensionen Stromversorgungsteil: 173 × 54 × 95 mm

  Herstellung Ausführung /22 in Belgien, Paladin 394 ist der Name für den deutschen Markt.

• Net weight (2.2 lb = 1 kg)
• 3 kg / 6 lb 9.7 oz (6.608 lb)

• Price in first year of sale
• 168.00 DM

• External source of data
• Erb

• Source of data
• HdB d.Rdf-& Ferns-GrH 1961/62

• Mentioned in
• -- Original-techn. papers.
