Philips Shortwave International 50IC361 /??

• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1971 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 325651

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave, more than 2 x SW plus FM or UHF.

• Power type and voltage
• Line / Batteries (any type) / 110-127; 220-240 / 6 x 1.5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Philips Shortwave International 50IC361 /?? - Philips; Eindhoven tubes

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 370 x 230 x 90 mm / 14.6 x 9.1 x 3.5 inch

• Notes

• 3 FM preset stations. FM 87.5 - 108 MHz.

  See also German version of the radio with FM range 87.5 - 104 MHz; Philips Hurricane

• Author
• Model page created by Mike Edwards † 25.10.21. See "Data change" for further contributors.
