Philitina Color 1100 10CX1100/00S

• Country
• Germany

• Manufacturer / Brand
• Philips Radios - Deutschland

• Year
• 1980 ??

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 237980

• • Brand: Deutsche Philips-Ges.

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Line / Batteries (any type) / 220 / 12 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Philitina Color 1100 10CX1100/00S - Philips Radios - Deutschland

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 265 x 280 x 330 mm / 10.4 x 11 x 13 inch

• Author
• Model page created by a member from A. See "Data change" for further contributors.
