Phono-Cassetten-Tonmeister 6987TAPC

Philips Radios - Deutschland

Data
Forum
Pictures
Collections

  • Year
  • 1978
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 194048
    • Brand: Deutsche Philips-Ges.

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 80 W (unknown quality)
  • Material
  • Various materials
  • from Radiomuseum.org
  • Model: Phono-Cassetten-Tonmeister 6987TAPC - Philips Radios - Deutschland
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 640 x 160 x 420 mm / 25.2 x 6.3 x 16.5 inch
  • Notes
  • HiFi-Phono-Cassetten-Steuergerät mit 2x40W, HiFi-Automatic-Plattenspieler GC018 mit Tonabnehmersystem Super M400II, HiFi-Cassetten-Recorder, Anschlüsse für zwei Lautsprecherkreise, Philips "St-4": "Stereo-4"-Raumklang-Effekt.
  • Source of data
  • -- Original prospect or advert
  • Mentioned in
  • Prospekt: Alle Klänge dieser Welt, Ausgabe 1978/79
  • Author
  • Model page created by Günter Döring. See "Data change" for further contributors.
