• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1956 ?

• Category
• Kit (Parts plus instruction) or building instructions only

• Radiomuseum.org ID
• 347462

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• ECH81

• Main principle
• TRF with regeneration

• Tuned circuits
• 1 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Powered by external power supply or a main unit.

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case, TUBES VISIBLE

• from Radiomuseum.org
• Model: Pionier Senior S101 - Philips; Eindhoven tubes

• Shape
• Chassis only or for «building in»

• Notes

• Philips Pionier Senior S101,  Radio Bausatz mit Röhre ECH81 als Einkreis-Empfänger.

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Adrian Riesen. See "Data change" for further contributors.
