Portable Record Reproducer AG4026 /90 /90A Ch= AG2026-90

• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1961 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 252985

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 5

• Semiconductors
• OC71 OC71 OC71 OC74 OC74

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Rec.Player+Audio.Amp+LS

• Power type and voltage
• Dry Batteries / D: 6 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 inch = 17.8 cm

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Portable Record Reproducer AG4026 /90 /90A Ch= AG2026-90 - Philips; Eindhoven tubes

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 335 x 155 x 245 mm / 13.2 x 6.1 x 9.6 inch

• Notes

• Portable record reproducer, 4 speed AG4026. Stereo pick-up cartridge AG3302 (crystal) or AG3202 (ceramic).

  Versions /90 and /90A differ only in cabinet color. See also Philips AG4026 without suffix.

• Net weight (2.2 lb = 1 kg)
• 3.2 kg / 7 lb 0.8 oz (7.048 lb)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Literature/Schematics (2)
• -- Schematic

• Author
• Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.
