RA90A-14
Philips akc. spol., Praha-Hloubetin
- Country
- Czechoslovakia
- Manufacturer / Brand
- Philips akc. spol., Praha-Hloubetin
- Year
- 1939 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 339986
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Bakelite case
- from Radiomuseum.org
- Model: RA90A-14 - Philips akc. spol., Praha-
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 450 x 320 x 220 mm / 17.7 x 12.6 x 8.7 inch
- Notes
-
See also models NSF-Aristona H90A (-20), Mediator M90A, SFR-Radiola RA90A, Mullard MAS90, Rektra RA90, Philips 480A.
- Mentioned in
- - - Manufacturers Literature (Generic model 90A by Philips dated 1939)
- Author
- Model page created by Gidi Verheijen. See "Data change" for further contributors.
