• Country
• Brazil

• Manufacturer / Brand
• Philips do Brasil S.A.

• Year
• 1975 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 240645

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 16

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 452/10700 kHz

• Wave bands
• Broadcast, 2 Short Wave plus FM or UHF.

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220; 240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 6 W (undistorted)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Radiofone 06RF445 - Philips do Brasil S.A.

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 520 x 205 x 345 mm / 20.5 x 8.1 x 13.6 inch

• Notes

• Two channel stereo

  Changer 06GC047 with cartridge GP200 or GC057 with cartridge GP215

  Speaker box included, model RH413 (2x) with speaker model AD3800/M



• Literature/Schematics (1)
• - - Manufacturers Literature

• Author
• Model page created by Antonio Rabitti. See "Data change" for further contributors.
