• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1964–1967

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 110117

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 2

• Valves / Tubes
• DY87 A47-11W

• Number of Transistors
• 50

• Semiconductors
• AD140 AC128 AC125 AC127 AF126 AF121 OC44 AF118 OC141 OC45 AU101 BCZ13 AF178 AF180 AF186 BYY21 BZ100 OA90 AA119 OA80 OA81 OA202 BYX10 BA100

• Main principle
• Superheterodyne (common)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Line / Batteries (any type) / 220 / 12 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Raffael Luxus All-Transistor 19TX430AT /00 /16 /38 - Philips; Eindhoven tubes

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 545 x 460 x 330 mm / 21.5 x 18.1 x 13 inch

• Notes

• VHF/UHF.

  50 Transistors and 21 Diodes, listed one per type.

• Net weight (2.2 lb = 1 kg)
• 19 kg / 41 lb 13.6 oz (41.85 lb)

• Price in first year of sale
• 1,448.00 DM

• Source of data
• Handbuch VDRG 1964/1965

• Literature/Schematics (1)
• -- Original-techn. papers.

• Literature/Schematics (2)
• -- Schematic (“Schemario TV Philips Service”, CELI Editor, Italy 1972.)

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
